A 5000 lbs A-Frame Top Wind Hand Trailer Jack is a heavy-duty, essential component for safely hitching, stabilizing, and leveling your trailer. Its robust "A-Frame" design integrates directly with the trailer's tongue, providing superior strength and stability.
The "Top Wind" feature means the lifting mechanism (a hand-operated crank) is located at the top of the jack post. This ergonomic design allows for easy operation, even when the trailer is close to the ground or when a heavy-duty coupler is in the way. The primary function of this jack is to effortlessly lift the trailer's tongue to connect or disconnect it from the tow vehicle's hitch, and to provide stable support when the trailer is parked.
| Feature | Specification / Description |
|---|---|
| Model / Type | A-Frame Trailer Jack, Top Wind / Crank Style |
| Lifting Capacity | 5,000 lbs (2,268 kg) |
| Mounting Style | A-Frame Bolt-On (Typically requires drilling and bolting to the trailer tongue) |
| Crank / Lift Location | Top Wind (Operation handle at the top of the jack tube) |
| Minimum Height (Closed) | Approximately 13.5 - 15.5 inches (343 - 394 mm) |
| Maximum Height (Extended) | Approximately 27 - 30 inches (686 - 762 mm) |
| Lift Travel / Range | Approximately 13.5 - 14.5 inches (343 - 368 mm) |
| Gear System | Multi-Speed (e.g., 2-Speed): High-Speed for raising/lowering, Low-Speed for heavy lifting. |
| Footplate | Large, Pivoting Steel Plate (Provides a stable base on uneven ground) |
| Construction Material | Heavy-Gauge Steel |
| Finish / Coating | Powder-Coated or Galvanized (For superior rust and corrosion resistance) |
| Wheel Option | Often includes an optional bolt-on wheel/caster for easy maneuvering. |
| Weight | Approximately 25 - 35 lbs (11 - 16 kg), depending on the model. |
| Key Features | - Robust A-Frame Design: For maximum strength and integration. - High Lifting Capacity: Handles heavy trailer tongues with ease. - Top Wind Crank: Ergonomic and accessible operation. - Multi-Speed Gearing: Balances speed and power. - Reinforced Footplate: Prevents sinking and provides stability. |
High Weight Capacity: Reliably supports up to 5000 lbs, making it suitable for a wide range of medium to heavy-duty trailers.
Ergonomic Operation: The top-wind design offers a comfortable and accessible cranking position in various hitching scenarios.
Superior Stability: The A-frame structure and wide footplate create a very stable base, preventing the trailer from wobbling.
Durability: Constructed from heavy-duty steel with a protective finish, it is built to last in tough environments.
Efficient Lifting: The multi-gear system allows you to raise the jack quickly when unloaded and switch to a power gear for the final, heavy lifting to engage the hitch.
