1.Product Introduction of the 10 Bolts Double Wheel Hub Trailer Axle
1). Special heat-treated, low-alloy steel axle beam, offers more stability, greater capacity and lighter weight.
2). Forged camshafts with hardened wear surface for the axle
3). Solid inserted spindle and bearing journals laser heat treated, provide superior fatigue capability.
4). High performance premium non-asbestos brake linings, extend service life.
5). Easy for ABS installation.
Semi Trailer Axle Fuwa Type -12 Ton 14 Ton 16 Ton Heavy Duty Trailer Axle
1.Product Introduction of the 10 Bolts Double Wheel Hub Trailer Axle
1). Special heat-treated, low-alloy steel axle beam, offers more stability, greater capacity and lighter weight.
2). Forged camshafts with hardened wear surface for the axle
3). Solid inserted spindle and bearing journals laser heat treated, provide superior fatigue capability.
4). High performance premium non-asbestos brake linings, extend service life.
5). Easy for ABS installation.
2.Product Parameter of the 10 Bolts Double Wheel Hub Trailer Axle
American series 13T inboard axle:
1) Track length: 1840mm;
2) Beam size: Square 150mm;
3) Brake: 420*180mm;
4) Wheel fixing: 10-M22*1.5 ISO, 10 holes;
5) PCD: 335mm;
6) Bearing: HM518445/10;
7) Recommended wheel rim: 7.50V-20
German Drum Series Axle & America Drum Series Axle for your choose:
| Model | Max.capacity (T) |
Track(mm) | Brake(mm) | Axle beam | P.C.D(mm) | Total length (mm) |
| Lahoo-10.5 | 10.5 | 1820 | 420x180 | φ127 | 285.75 | 2165 |
| Lahoo-13 | 13 | 1840 | 420x180 | 150x150 | 285.75 | 2185 |
| Lahoo-15 | 15 | 1850 | 420x180 | 150x150 | 335 | 2185 |
| Lahoo-16 | 16 | 1850 | 420x220 | 150x150 | 335 | 2185 |
| Lahoo-14 | 14 | 1840 | 420x200 | 150x150 | 281 | 2175 |
Remark: Other track length and ABS & automatic slack adjuster is available.
|
1. Production : |
12T Germany type semi trailer axle for heavy duty truck |
|
12T, 14T, 16T , |
|
|
2. Axle types: |
American type axle, Germany type axle , European type axle , Thai type axle, Brazil axle, South Africa type axle, |
|
Spoke type axle , drum inboard type axle , drum outboard axle |
|
|
FUWA type axle, BPW type axle , York axle, |
|
|
3. Axle beam type: |
Square beam 150x150mm, Round beam 127mm diameter, |
|
4. Track: |
1820mm, 1840mm, 1850mm |
|
5.Brake size: |
420x180mm, 420x200mm, 420x220mm |
|
5. Components: |
Axle main beam, brake drum, brake shoe, brake lining, wheel hub, Slack adjuster, S-cam shaft, bearing, wheel bolt, axle cover. |
|
6. Color |
Red, shinning black, dark black, grey, blue, As requirement. |
|
7. Warranty: |
12 months since shipping date. |
|
8. Related Certificate: |
ISO9001; TS16949; COC; PVOC; CIQ; SONCAP; BV; C/O; FORM E. |
|
9. Axle Application: |
Light duty trailer, heavy duty semi trailer, truck , agricultural trailer, |
|
10. Production ability: |
8000 Pcs per month |
|
11. Shipping : |
58 pcs /1x20 feet container |
|
12. Lead time: |
About 15-20 Working Days |
