1. From 0.5 to 100 liters. Other sizes and models available on request.
2. Temperature range: -50 ° C to +50 ° C
3. Pressure range: 10 to 19 bar, 150 to 275 Psi, 1 to 1.9 Mpa
4. Port: According to customer requirements.
5. Norms thread M 22 x 1.5 or NPT or NPTF
6. Mounting Bracket: According to customer requirements.
7. Color: Power coating, Polishing, Anodizing
| Item No. | Material | Tank Dia. (mm) |
Length H (mm) |
Volume(lt) | Port Size | Port Qty | Max. Pressure | Max. Working Temperature |
Surface Treatment |
| LH130130 | Aluminum/Steel | 130 | 130 | 1.5 | 1/4"NPT, 3/8"NPT, 1/2"NPT | As requested | 200PSI | -10-60℃ | Painted/ Polishing/ Anodizing |
| LH130175 | Aluminum/Steel | 130 | 175 | 2 | 1/4"NPT, 3/8"NPT, 1/2"NPT | As requested | 200PSI | -10-60℃ | Painted/ Polishing/ Anodizing |
| LH130350 | Aluminum/Steel | 130 | 350 | 6 | 1/4"NPT, 3/8"NPT, 1/2"NPT | As requested | 200PSI | -10-60℃ | Painted/ Polishing/ Anodizing |
| LH160220 | Aluminum/Steel | 160 | 220 | 4.5 | 1/4"NPT, 3/8"NPT, 1/2"NPT | As requested | 200PSI | -10-60℃ | Painted/ Polishing/ Anodizing |
| LH190330 | Alumunum/Steel | 190 | 330 | 9 | 1/4"NPT, 3/8"NPT, 1/2"NPT | As requested | 200PSI | -10-60℃ | Painted/ Polishing/ Anodizing |
| LH190420 | Aluminum/Steel | 190 | 420 | 12 | 1/4"NPT, 3/8"NPT, 1/2"NPT | As requested | 200PSI | -10-60℃ | Painted/ Polishing/ Anodizing |
| LH220400 | Aluminum/Steel | 220 | 540 | 20 | 1/4"NPT, 3/8"NPT, 1/2"NPT | As requested | 200PSI | -10-60℃ | Painted/ Polishing/ Anodizing |
| LH245540 | Aluminum/Steel | 245 | 540 | 24 | 1/4"NPT, 3/8"NPT, 1/2"NPT | As requested | 200PSI | -10-60℃ | Painted/ Polishing/ Anodizing |
