1. It is widely applied for air suspension system
2. Aluminum air tanks are lighter than steel and stainless steel tanks
3. A fresher aesthetic, stronger resistance in rust
4. Seamless better sealing
5. The air tanks comply with CE & SAE J10 Standard
6. Rated working pressure : 200psi
7. Finish, anodized, polished, powder coating
8. Ports can be BSP, G Thread etc
Product Parameters
| Item No. | Material | Tank Dia. (mm) |
Length (mm) |
Volume (It) |
Port Size | Port Q'ty | Max. Pressure |
Max. Working Temperature |
Surface Treatment |
| LH080200 | Aluminum/Steel | 88 | 200 | 1 | NPT/BPS/G Thread | request | 200 PSI | -10-60 ºC | Painted/Polishing/Anodizing |
| LH100190 | Aluminum/Steel | 100 | 190 | 1.4 | NPT/BPS/G Thread | request | 200 PSI | -10-60 ºC | Painted/Polishing/Anodizing |
| LH130100 | Aluminum/Steel | 130 | 100 | 1 | NPT/BPS/G Thread | request | 200 PSI | -10-60 ºC | Painted/Polishing/Anodizing |
| LH130130 | Aluminum/Steel | 130 | 130 | 1.5 | NPT/BPS/G Thread | request | 200 PSI | -10-60 ºC | Painted/Polishing/Anodizing |
| LH130175 | Aluminum/Steel | 130 | 175 | 2 | NPT/BPS/G Thread | request | 200 PSI | -10-60ºC | Painted/Polishing/Anodizing |
| LH150350 | Aluminum/Steel | 150 | 350 | 6 | NPT/BPS/G Thread | request | 200 PSI | -10-60 ºC | Painted/Polishing/Anodizing |
| LH160220 | Aluminum/Steel | 160 | 220 | 4.5 | NPT/BPS/G Thread | request | 200 PSI | -10-60ºC | Painted/Polishing/Anodizing |
| LH190330 | Aluminum/Steel | 190 | 330 | 9 | NPT/BPS/G Thread | request | 200 PSI | -10-60 ºC | Painted/Polishing/Anodizing |
| LH190420 | Aluminum/Steel | 190 | 420 | 12 | NPT/BPS/G Thread | request | 200 PS | -10-60 ºC | Painted/Polishing/Anodizing |
| LH220400 | Aluminum/Steel | 220 | 540 | 20 | NPT/BPS/G Thread | request | 200 PSI | -10-60ºC | Painted/Polishing/Anodizing |
| LH245400 | Aluminum/Steel | 245 | 400 | 19 | NPT/BPS/G Thread | request | 200 PS | -10-60 ºC | Painted/Polishing/Anodizing |
| LH245540 | Aluminum/Steel | 245 | 540 | 24 | NPT/BPS/G Thread | request | 200 PSI | -10-60 C | Painted/Polishing/Anodizing |
| LH330590 | Aluminum/Steel | 330 | 590 | 50 | NPT/BPS/G Thread | request | 200 PS | -10-60 ºC | Painted/Polishing/Anodizing |
| Note: We Accept Customer Size Customization | |||||||||
